Description
Mitee-Bite Knife Edge Clamps can be used instead of the original brass hex clamps for clamping rough cut stock, castings, and any material that requires a hardened clamping element. These use the same “G” measurement as the original Fixture Clamp.
Click on the Part # hyperlink to download CAD models.
Part # |
A |
B |
C |
D |
E |
F |
G |
Clamps
|
Torque
|
Holding Force (N.) |
| 82584 | M10 | 7M | 1.27 | 20.60 | 6.35 | 19 | 10.15 | 8 | 28 | 8,900 |
| 82588 | M12 | 8M | 2.03 | 25.4 | 9.52 | 22.8 | 12.7 | 8 | 88 | 17,800 |
| 82592 | M16 | 12M | 2.54 | 30.15 | 12.7 | 28.5 | 15 | 4 | 135 | 26,700 |
*Not designed for clamping hardened material at listed torque.
